- Customizable
- Automatic metering
- Automatic billing
- 4G/5G wireless communication
- Scan to charge
- Electric vehicle charging
| Serial Number | Unit | Indicator | Indicator Value |
|---|---|---|---|
| 1 | Product Model | JAVS28 – 4D | |
| 2 | Gun Quantity | Dual Guns | |
| 3 | Input Power Parameters | Input Voltage | Single – phase AC220V |
| Input Frequency | 45 – 65Hz | ||
| Rated Power | 7KW | ||
| Maximum Input Current | 32A | ||
| Input Power Factor | ≥0.99 | ||
| 4 | Output Power Parameters | Output Voltage | AC220V |
| Single – Gun Output Current | 0 – 32A | ||
| Charging Cable Length | 5m | ||
| Metering Accuracy | Class 1 | ||
| Current Limiting Protection Value | ≥110% | ||
| 5 | Electrical Indicators | Temperature Regulation Accuracy | ≤±1% |
| Ripple Coefficient | ≤±0.5% | ||
| Efficiency | ≥94% | ||
| Power Factor | ≥0.99 (above 50% load) | ||
| Total Harmonic Distortion THD | ≤5% (above 50% load) | ||
| Execution Standard | GB/T 20234, GB/T 18487, GB/T 27930, GB/T 33008 | ||
| 6 | Safety Design | Safety Functions | Temperature detection, over – load protection, short – circuit protection, grounding protection, over – temperature protection |
| 7 | Others | Payment Methods | QR code payment, card payment, APP payment |
